Single battery Trolley Inverter Battery Replacement (1 x 100Ah Vestwoods Lithium Ion LiFe PO4 battery including free Bluetooth App)
.
If your Trolley Inverter / Intellipower is no longer working, it is often due to the unit needing battery replacement. Batteries are consumables and need to be replaced once depleted.
We will clean the unit out, replace lugs if needed, replace the battery and quote on any other necessary repairs to the unit.
Should the unit not need battery replacement when you bring it in, we will let you know this and quote on what does need to be done to restore the unit to perfect working condition.
.
Battery replacement price includes the credit for the scrap (old) battery inside the unit which we will retain. Should you wish to keep these old battery there will be an addittional charge of @265+vat per battery.
.
If you book for your battery replacement in advance, we can do this whilst you wait. It takes about 30mins.
.
If you are unable to bring the unit to our workshop in Kyalami, we would gladly come to you for an additional call out fee. NB: When Load Shedding causes demand to increase we have to decline call outs due to a lack of man power. Call our offices on 011-468-1619 to discuss this option.
.
BATTERY SELECTION: You have chosen a Lithium Ion battery which comes with a 3 year conditional manufacturers carry in warranty held by the battery manufacturer & supplier.
Vestwoods VC12100 12.8V 100AH LITHIUM-ION BATTERY
Safe and Reliable
The Safest LFP battery cell
Cell balancing to extend the lifetime of the battery (>300mA)
Bluetooth built-in makes it easy to access battery status (Pow Bank)
Supports series and parallel use (maximum 4)
Electrical
Nominal Voltage/V 12.8
Nominal Capacity/Ah 100
Rated Energy/Wh 1280
BMS Function Overcharge, overdischarge, overcurrent and temperature protection
Recommended Charge Voltage/V 14.4 - 14.6
Discharge Cut-off Voltage/V 10.8
Standard Charge Current/A 50
Max. Charge Current/A 100
Continuous Discharge Current/A 100
Peak Discharge Current/A@5S 300
Voltage Configurations 12,24,36 or 48V
Maximum Configuration Increase capacity in series or increasing voltage parallel
Maximum Time Between Charges 3 months
Monitoring Bluetooth
Mechanical
Dimension(L*W*H)/ mm 307*169*213
Weight/kg Approx.11.5
Terminal M8
Casing material ABS
Environment
Working Temperature Range/℃ Charge : 0~55 Discharge: -20~60
Humidity Range/RH ＜95%
Storage temperature/℃ 15~35
IP protection level IP65
Download battery spec sheet here: RTVC12100
For estimated run time total your watts and refer to the run time chart here
